CH4 (Methane) Gas Sensor

The CH4 Gas Sensor is used in gas detection equipment for detecting Methane in home, automotive or industrial settings.


Key Features:

• Manufacturer Model MQ-2.
• Wide detecting scope.
• Stable and long life.
• Simple drive circuit.
• Fast response and high sensitivity.


Application Ideas:

• Safety Devices (harmful gas detection).
• Environmental monitoring.


Details:

• Voltage requirements: 5VDC.
• Current requirements: ~160mA.
• Interface Type: Resistive.
• Dimensions: 0.75" diameter x 0.65" tall excluding leads (19.1mm diameter x 16.55mm tall excluding leads).
• Operating temp range: -4 to 122 °F (-20 to 50 °C).


NOTE: Please refer to the manufacturer datasheet for more informatoin and circuit recommendations.
